MHC-800 AUTO H-BEAM GAS CUTTING MACHINE
Kim Tai Welding Supply Sdn BhdType: Sale
WeldRo MHC-800 H-Beam Cutting Machine is a portable automatic H-beam oxy-fuel cutting machine
Description
WeldRo MHC-800 H-Beam Cutting Machine is a portable automatic H-beam oxy-fuel cutting machine. It is possible to perform fast and precise web and flange cuts on beam profiles.
The machine features two drive motors: one for web cutting, the other for flange cutting. For cutting webs the carriage travels along the guide rail, for cutting flanges the torch is moved by a vertical gear rack. It eliminates the need for secondary operations.
The machine features two drive motors: one for web cutting, the other for flange cutting. For cutting webs the carriage travels along the guide rail, for cutting flanges the torch is moved by a vertical gear rack. It eliminates the need for secondary operations.
FEATURES
- Guide rail and main unit are connected (short installation time)
- Low weight (It is more economic to transport the machine to the work piece)
- Diagonal cuts at the web and flange as well as beveling is possible till 45°
- SCR control unit for steady feed
- Plasma Torch Attachment available and sold as optional accessories
TECHNICAL DATA
| MSP-5 AUTO GAS PIPE CUTTING MACHINE | |
| PRODUCT CODE | K155/110 |
| INPUT VOLTAGE | 240VAC, 50Hz |
| CUTTING THICKNESS | 6 – 60 mm |
| TRAVEL SPEED | 50 – 700 mm/min |
| CUTTING WIDTH CUTTING HEIGHT |
150 – 800 mm/min 150 – 400 mm/min |
| EDGE CUTTING PROFILE | 0 – 45 Degree |
| WEIGHT | 30 kg |
